Description

GEPRC EM2807-1350KV MOTOR

Introducing the GEPRC EM2807 Motor – 1350KV, meticulously crafted for the demands of long-range FPV enthusiasts. With a robust M5 steel shaft, this motor ensures unwavering durability. Its high torque magnetic circuit design guarantees efficient power delivery, while the compact 19mm x 19mm base allows for versatile mounting options. Elevate your FPV experience with the reliability and performance of the GEPRC EM2807 Motor – 1350KV.

FEATURES:

• New EM series motors，mainly designed for long range FPV.
• High-strength M5 steel shaft
• High torque magnetic circuit design
• 19mmx19mm base

SPECIFICATIONS:

• Model: EM2807 1350KV Motor
• Max Watt: 1080W
• Peak current: 47A
• Interphase resistance: 45mΩ
• Propeller: 6-8inch Propeller
• Magnet: N52H
• Bearing type: NSK/NMB
• Configuration: 12N14P
• Dimension: φ33mmx20.1mm
• Shaft Diameter: φ5mm
• Shaft Protruding Length: 16mm
• Mounting holes: 19mmx19mm
• Lead: 260mm/18AWG
• ESC: 50A-60A
• Input Volts: 25.2V（6S LiPo)
• Winding: Single strand copper winding
• Weight: 57g(included wire)
• Suitable for :7-8 inch long range FPV

INCLUDES:

• 1x EM2807 motor
• 4 x M3*9 round head screws
• 1 x M5 anti-slip nut
