GEPRC MOMODA2 5.8G RHCP SMA DUAL ANTENNA-90MM

Description

GEPRC MOMODA2 5.8G RHCP SMA DUAL ANTENNA-90MM

The GEPRC Momoda2 DUAL uses a dual-core RF design for enhanced gain and coverage in FPV video links. This listing is for the RHCP, 90mm, SMA version.

FEATURES

• Dual-core RF design with 3.8 dBi gain.
• Low VSWR for efficient signal transmission.
• Ultrasonically welded ABS housing.
• FPC + PCB antenna construction.
• Individually tested by GEPRC using a spectrum analyzer.

SPECIFICATIONS

• Brand: GEPRC
• Model: Momoda2 5.8G DUAL
• Version: 90mm
• Polarization: RHCP
• Connector: SMA
• Center frequency: 5.65 GHz
• Frequency range: 5.3–6 GHz
• Gain: 3.8 dBi
• VSWR: ≤1.43
• Axial ratio: ≤3
• Radiation efficiency: 85%
• Cross-polarization suppression: −25 dB
• Construction: FPC + PCB
• Housing: ABS

PACKAGE CONTENTS

• 1 × GEPRC MOMODA2 5.8G RHCP SMA DUAL ANTENNA-90MM

Compatibility: Check that your equipment uses an SMA connection and matching RHCP polarization. DUAL refers to the antenna design; this package contains one antenna.

Illustrative images adapted from the 170mm model to represent the 90mm RHCP version.
