TRUERC SINGULARITY 5.8 LHCP U.FL WITH TUBE 160MM ANTENNA

TrueRC SINGULARITY 5.8 LHCP antenna in a custom 160 mm configuration with a protective tube and U.FL connector. Supplied as one antenna.

The photo is a close-up of the antenna head and tube. The supplied custom version has a 160 mm nominal length, as shown in the labelled schematic.

FEATURES:

• Compact circularly polarized antenna
• Protective tube configuration
• Custom 160 mm nominal length

SPECIFICATIONS:

• Frequency range: 5.6–6.0 GHz
• Gain: 1.9 dBic
• Radiation efficiency: 99%
• SWR: ≤1.5:1
• Cross-polar rejection: -15 to -30 dB
• Antenna head: 11.8 mm diameter × 8.2 mm high
• Polarization: LHCP
• Connector: U.FL
• Configuration: With tube
• Nominal length: 160 mm

PACKAGE CONTENTS:

• 1 × TrueRC SINGULARITY 5.8 LHCP U.FL antenna with tube, 160 mm
